Description
white phosphorus nvg goggles NODS QTNVG White/Green Phosphorus Night Vision GogglesThis 1X binoculars night vision goggles gen 3 gen2+, its FOV 50 degree better than PVS 3140m. Our new design is compact, lightweight dual night vision binoculars. They utilize two high performance image intensifier phosphorus tubes to provide extremely clear and crisp images under the darkest conditions. A built in IR illuminator lets the users easily read a map and function in a total darkness environment. NOTICE: LEAD TIME IS 3 4 WEEKS AS WE DO NOT
This 1X binoculars night vision goggles gen 3 gen2+, its FOV 50 degree better than PVS 3140m. Our new design is compact, lightweight dual night vision binoculars. They utilize two high performance image intensifier phosphorus tubes to provide extremely clear and crisp images under the darkest conditions. A built-in IR illuminator lets the users easily read a map and function in a total darkness environment.
NOTICE: LEAD TIME IS 3 - 4 WEEKS AS WE DO NOT KEEP UNITS IN STOCK DUE TO LOW SALE NUMBERS BUT COMPARED TO USA 6 MONTHS WAITING LIST WE ARE FASTER.
This 1X binoculars night vision goggles gen 3 gen2+ is designed to handle every budget and mission requirement and is a high performance choice!
|
MODEL
|
PVS-3140NVG
|
|
Structural design
|
Flip up helmet mounted
|
|
Automatically detect and power off when flip up
|
|
|
Battery type
|
Lithium battery (cr123x1) / cr123x4 external battery box
|
|
Power supply
|
2.6-4.2V
|
|
Control mode
|
ON/IR/AUTO
|
|
Over power consumption
|
<0.1W / 0.1w
|
|
Battery capacity
|
800-3200maH
800-3200maH |
|
Battery life
|
40-100hrs
|
|
Magnification
|
1X
|
|
FOV
|
40°
|
|
IIT
|
Gen2+ / 3
|
|
Lens system
|
F1.18 22.5mm
|
|
Resolution
|
64LP/mm
|
|
Optical distortion
|
3% Max
|
|
Relative Illumination
|
>75%
|
|
Coating
|
Multi-layer broadband coating
|
|
Focal Range
|
250mm-∞
|
|
Focus mode
|
manual focus
|
|
Eye relief
|
30mm
|
|
Eyepiece aperture
|
8mm
|
|
Eye distance adjustment range
|
50-80mm
|
|
Eye distance locking method
|
Manual locking
|
FEATURES:
1. IP65 orIP67 weatherproof;
2. Low battery indication;
3. Bright source protection;
4. Mil-spec multi-coated optic;
5. Automatic brightness control;
6. Fully adjustable head mount;
7. Embedded spring in battery’s cap;
8. Automatic shut off when flipped up;
9. No power consumption when in standby;
10. Large IPD range.
The new PVS-3140-MOD is a dual-tube goggle system with ergonomic design and improved functionality. It accommodates features such as a dedicated Instant-On-IR button to quickly and momentarily engage IR illuminator without having to operate the switch.
The connector located at the front of the unit is used to supply power to the unit from almost any power source: external battery pack, USB power bank, 12V car socket and so on. By customer's request, the unit can be equipped with Bayonet (PVS) or Dove-Tail style bracket.
Thanks to dual-tube design, PVS-3140-MOD delivers depth perception and allows using PVS-3140-MOD to operate various machines, boats etc., in addition to basic ground operations. A dual-tube night vision system has proved to be safer and more effective in low-light conditions compared to a “bi-ocular” system, commonly known as “PVS-7”, which is a “one lens-two eyes” type of NVD.
Technical Data
- Optical Magnification: 1x
- Objective Lenses: 27mm
- Focus Range: 0.25m .. Infinity
- Field of View: 40º
- Diopter Adjustment Range: -6 .. +4
- Interpupillary Adjustment Range: 50mm .. 90mm
- Built-In IR Illuminator: Yes
- Momentary IR-On Button: Yes
- IR-On Indicator: Yes
- MIL-SPEC Switch: Yes
- Bright Light Protection: Yes
- Automatic Light Overload Shut-off System: Yes
- Low Battery Indicator: Yes
- Stow Safety Feature: Yes
- Flip-up-off Feature: Yes
- Selective Channel Engagement: Yes
- Any Polarity Battery Insertion: Yes
- Power Source: 1pc AA or 1pc CR123
- Battery Life: up to 40 Hours
- External Power: 4VDC .. 15VDC
- Operating Temperature: -40C .. +50C
- Dimensions: 112x105x70mm
- Weight: 650g
- Warranty: 7 Years, Limited
- Export: Available for Export Worldwide
-
Made In Canada, Non-ITAR System
