MIDI Out :

• Bluetooth MIDI out
• USB host MIDI out with 5V power out
• USB device MIDI out
• 5-Pin MIDI out x 2
• Send all kinds MIDI messages

MIDI In :

• Bluetooth MIDI in
• USB host MIDI in with 5V power out
• USB device MIDI in
• 5-Pin MIDI in
• MIDI in can through to all MIDI out
• MIDI in with CC and PC, can trigger to all message types

HID Out :

• Bluetooth HID out
• Send all kinds HID messages of keyboard

Footswitch Out :

• Footswitch out x 4 on 2 ¼" TRS jacks
• Momentary and latching action support

Expression pedal In :

• Expression pedal in x 2
• Support all expression pedal types
• Send MIDI CC messages to all MIDI out

LED Indicator :

• System LED x 1
• Individual footswitch LED x 5
• Blue and Green
• Normal and toggle mode

AIRSTEP Lite :

• No 5-Pin MIDI interface
• No footswitch out
• No USB
• No expression pedal input
• Only has Bluetooth MIDI and HID out
• Can be used as a wireless extension footswitch for AIRSTEP

Footswitches :

• Footswitches x 5
• Footswitch action assignable to press, release and long-press

Message Send :

• Message can be triggered by footswitches, MIDI in and expression pedal
• Message type: MIDI, HID, Footswitch, Device
• Send up to 8 messages in one trigger
• Each message can assign different physical output interfaces
• Normal and toggle message mode

APP Editor :

• Each MIDI trigger and footswitch message can be flexibly edited by APP
• Connect to AIRSTEP by Bluetooth
• iOS and Android support
• All editable data can be saved as presets
• Unlimited number of presets can be saved and loaded into AIRSTEP
• XSONIC library of presets for all your favorite devices

AIRSTEP Local Preset :

• Up to 5 presets can be stored in AIRSTEP locally
• Local preset can be switched by all triggers, FUNC button, and APP
• Local presets can work without APP

Battery Power Supply :

• AIRSTEP is battery powered and rechargeable by 5V - 9V DC
• 300 hours of continuous use
• USB power supply current can't exceed 150mA.

Firmware :

• Firmware can be updated by Bluetooth and USB

Wireless Communication Distance :

• 30m (100') line of sight(LOS), between AIRSTEP and phone, tablet, computer
• 30m (100') line of sight(LOS), between AIRSTEP and AIRSTEP Lite

Bluetooth Communication Latency :

• 10ms, between AIRSTEP and AIRSTEP Lite
• 20ms, between AIRSTEP and smart devices

Appearance :

• Robust aluminum extruded shell
• Rotatable and detachable external antenna
• 300 x 70 x 45(H) mm
• AIRSTEP 700g | AIRSTEP Lite 650g

Compatible Device :

• IOS device：iOS 10 and above
• Mac device：OS X 10.6 and above
• Android device：Android 7.0 and above
• Windows device：Windows 10
